From Ecopath with Ecosim to Fisheries Integrated Modeling System

An Ecosystem-to-Stock-Assessment Simulation Workflow using {ecosystemom}

ewe-ecosim-base-simulation.Rmd

Introduction

Ecosystem-based fishery management (EBFM) is crucial for addressing the complex, dynamic challenges posed by non-stationary climate, ecological, and economic conditions. However, translating outputs from ecosystem models into products suitable for fishery stock assessment models remains a key challenge.

This vignette demonstrates an end-to-end simulation workflow implemented in the {ecosystemom} package for linking ecosystem model outputs with fisheries estimation models. The workflow includes functions to:

  • load_model() — import and standardize output from ecosystem operating models (OM). For example, this function can be used to read and standardize Ecopath with Ecosim (EwE) Ecosim outputs for downstream analyses within {ecosystemom}.
  • get_truth() — extract “true” population quantities from the OM, including annual or monthly biomass trajectories and biomass-at-age.
  • sample_*() — generate sampled observations from OM outputs for use in estimation models such as the Fisheries Integrated Modeling System (FIMS).
  • create_dsem_inputs() — prepare environmental covariates or diet composition data from the OM to support candidate model specifications for dynamic structural equation models (DSEMs) and related ecosystem-informed analyses.

Load EwE Model Outputs

We begin by identifying and parsing raw comma-separated output matrices exported from a baseline EwE model run of the Northwest Atlantic. The critical target files extracted by {ecosystemom} include:

  • basic_estimates.csv
  • biomass_monthly.csv
  • catch_monthly.csv
  • diet_composition.csv
  • mortality_monthly.csv
  • weight_monthly.csv

Get functional groups from the EwE model

# Locate package internal files
ewe_nwatlantic_path <- system.file(
  "extdata", "ewe_ecosim_base_nwatlantic",
  package = "ecosystemom"
)

model_years <- 1985:2017

# Load functional groups
functional_groups <- get_functional_groups(
  file_path = fs::path(ewe_nwatlantic_path, "basic_estimates.csv")
)

functional_groups |>
  scroll_table()
functional_group species group functional_group_snake_case
striped bass 0 striped bass 0 striped_bass_0
striped bass 2-5 striped bass 2-5 striped_bass_2_5
striped bass 6+ striped bass 6+ striped_bass_6_plus
menhaden 0 menhaden 0 menhaden_0
menhaden 1 menhaden 1 menhaden_1
menhaden 2 menhaden 2 menhaden_2
menhaden 3 menhaden 3 menhaden_3
menhaden 4 menhaden 4 menhaden_4
menhaden 5 menhaden 5 menhaden_5
menhaden 6+ menhaden 6+ menhaden_6_plus
spiny dogfish spiny dogfish NA spiny_dogfish
bluefish juv bluefish juv bluefish_juv
bluefish adult bluefish adult bluefish_adult
weakfish juv weakfish juv weakfish_juv
weakfish adult weakfish adult weakfish_adult
Atlantic herring 0-1 Atlantic herring 0-1 atlantic_herring_0_1
Atlantic herring 2+ Atlantic herring 2+ atlantic_herring_2_plus
anchovies anchovies NA anchovies
benthos benthos NA benthos
zooplankton zooplankton NA zooplankton
phytoplankton phytoplankton NA phytoplankton
Detritus Detritus NA detritus

Load EwE Ecosim model

# Load and standardize EwE outputs
data_om <- load_model(
  directory = ewe_nwatlantic_path,
  functional_groups = functional_groups,
  type = "ewe_ecosim",
  unit = c(
    "biomass" = "1e^6 mt",
    "catch" = "1e^6 mt",
    "landings" = "1e^6 mt",
    "total_mortality" = "year^-1",
    "weight" = "NA"
  )
)
#> Warning: Detected negative natural mortality in year(s): 1985, 1986, 1987, 1988, 1996,
#> 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009.
#> ℹ We used 0 for those negative natural mortality values for now.
#> ℹ Please check the Ecosim fishing mortality input. Are the input values
#>   reasonable? Is catch greater than biomass?

data_om |>
  head(n = 10) |>
  dplyr::mutate(file_name = "./biomass_monthly.csv") |>
  scroll_table()
file_name type year month functional_group value species group functional_group_snake_case unit
./biomass_monthly.csv biomass 1985 1 striped bass 0 0.0084961 striped bass 0 striped_bass_0 1e^6 mt
./biomass_monthly.csv biomass 1985 1 striped bass 2-5 0.0362939 striped bass 2-5 striped_bass_2_5 1e^6 mt
./biomass_monthly.csv biomass 1985 1 striped bass 6+ 0.0186583 striped bass 6+ striped_bass_6_plus 1e^6 mt
./biomass_monthly.csv biomass 1985 1 menhaden 0 0.2910449 menhaden 0 menhaden_0 1e^6 mt
./biomass_monthly.csv biomass 1985 1 menhaden 1 0.9729747 menhaden 1 menhaden_1 1e^6 mt
./biomass_monthly.csv biomass 1985 1 menhaden 2 0.7663768 menhaden 2 menhaden_2 1e^6 mt
./biomass_monthly.csv biomass 1985 1 menhaden 3 0.3195014 menhaden 3 menhaden_3 1e^6 mt
./biomass_monthly.csv biomass 1985 1 menhaden 4 0.1119810 menhaden 4 menhaden_4 1e^6 mt
./biomass_monthly.csv biomass 1985 1 menhaden 5 0.0409002 menhaden 5 menhaden_5 1e^6 mt
./biomass_monthly.csv biomass 1985 1 menhaden 6+ 0.0314173 menhaden 6+ menhaden_6_plus 1e^6 mt

data_om |>
  dplyr::distinct(type, species) |>
  scroll_table()
type species
biomass striped bass
biomass menhaden
biomass spiny dogfish
biomass bluefish
biomass weakfish
biomass Atlantic herring
biomass anchovies
biomass benthos
biomass zooplankton
biomass phytoplankton
biomass Detritus
catch striped bass
catch menhaden
catch spiny dogfish
catch bluefish
catch weakfish
catch Atlantic herring
catch anchovies
catch benthos
catch zooplankton
catch phytoplankton
catch Detritus
total_mortality striped bass
total_mortality menhaden
total_mortality spiny dogfish
total_mortality bluefish
total_mortality weakfish
total_mortality Atlantic herring
total_mortality anchovies
total_mortality benthos
total_mortality zooplankton
total_mortality phytoplankton
total_mortality Detritus
weight striped bass
weight menhaden
weight spiny dogfish
weight bluefish
weight weakfish
weight Atlantic herring
weight anchovies
weight benthos
weight zooplankton
weight phytoplankton
weight Detritus
fishing_mortality striped bass
fishing_mortality menhaden
fishing_mortality spiny dogfish
fishing_mortality bluefish
fishing_mortality weakfish
fishing_mortality Atlantic herring
fishing_mortality anchovies
fishing_mortality benthos
fishing_mortality zooplankton
fishing_mortality phytoplankton
fishing_mortality Detritus
natural_mortality striped bass
natural_mortality menhaden
natural_mortality spiny dogfish
natural_mortality bluefish
natural_mortality weakfish
natural_mortality Atlantic herring
natural_mortality anchovies
natural_mortality benthos
natural_mortality zooplankton
natural_mortality phytoplankton
natural_mortality Detritus

Extract “Truth” from the OM

Using get_truth(), we synthesize raw EwE time series into a structured tibble. This “truth” represents the true state of the ecosystem against which our estimation model will be tested. For this demonstration, our focal species is “menhaden”. To isolate a target stock assessment from the broader ecosystem web, we subset a single focal species from the OM. In this vignette, we track Atlantic Menhaden (Brevoortia tyrannus), a key forage fish species. We extract “true” indices and age compositions using get_truth().

# Extract "true" values for menhaden
truth_om <- get_truth(
  data = data_om,
  species_name = "menhaden"
)

truth_om |>
  dplyr::select(-truth_om) |>
  scroll_table()
species_name truth_label truth_type truth_time_step
menhaden biomass index monthly
menhaden biomass index yearly
menhaden biomass agecomp monthly
menhaden biomass agecomp yearly
menhaden catch index monthly
menhaden catch index yearly
menhaden catch agecomp monthly
menhaden catch agecomp yearly
menhaden fishing_mortality index monthly
menhaden fishing_mortality index yearly
menhaden fishing_mortality agecomp monthly
menhaden fishing_mortality agecomp yearly
menhaden natural_mortality agecomp monthly
menhaden natural_mortality agecomp yearly
menhaden numbers index monthly
menhaden numbers index yearly
menhaden numbers agecomp monthly
menhaden numbers agecomp yearly
menhaden total_mortality agecomp monthly
menhaden total_mortality agecomp yearly
menhaden weight agecomp monthly
menhaden weight agecomp yearly


# Extract and unnest annual catch
biomass_scalar <- 1000000
catch_index_om <- truth_om |>
  dplyr::filter(
    truth_label == "catch",
    truth_type == "index",
    truth_time_step == "yearly"
  ) |>
  tidyr::unnest(cols = c(truth_om)) |>
  dplyr::mutate(
    truth_value = truth_value * biomass_scalar,
    truth_unit = "mt"
  )

catch_index_om |>
  scroll_table()
species_name truth_label truth_type truth_time_step truth_year truth_unit truth_value
menhaden catch index yearly 1985 mt 16436.46
menhaden catch index yearly 1986 mt 16565.34
menhaden catch index yearly 1987 mt 15939.05
menhaden catch index yearly 1988 mt 12596.12
menhaden catch index yearly 1989 mt 25993.96
menhaden catch index yearly 1990 mt 321014.86
menhaden catch index yearly 1991 mt 258893.40
menhaden catch index yearly 1992 mt 365211.37
menhaden catch index yearly 1993 mt 600358.51
menhaden catch index yearly 1994 mt 659307.57
menhaden catch index yearly 1995 mt 604887.34
menhaden catch index yearly 1996 mt 907276.10
menhaden catch index yearly 1997 mt 771183.60
menhaden catch index yearly 1998 mt 878034.15
menhaden catch index yearly 1999 mt 981962.22
menhaden catch index yearly 2000 mt 961678.94
menhaden catch index yearly 2001 mt 926563.53
menhaden catch index yearly 2002 mt 933937.94
menhaden catch index yearly 2003 mt 435965.57
menhaden catch index yearly 2004 mt 292324.12
menhaden catch index yearly 2005 mt 66979.80
menhaden catch index yearly 2006 mt 58767.23
menhaden catch index yearly 2007 mt 36368.17
menhaden catch index yearly 2008 mt 41439.10
menhaden catch index yearly 2009 mt 42480.31
menhaden catch index yearly 2010 mt 42963.63
menhaden catch index yearly 2011 mt 47277.22
menhaden catch index yearly 2012 mt 91043.37
menhaden catch index yearly 2013 mt 87008.47
menhaden catch index yearly 2014 mt 120764.99
menhaden catch index yearly 2015 mt 119770.21
menhaden catch index yearly 2016 mt 110616.90
menhaden catch index yearly 2017 mt 175165.13

# Extract and unnest annual weight-at-age
weight_scalar <- 738 / 1000000
weight_agecomp_om <- truth_om |>
  dplyr::filter(
    truth_label == "weight",
    truth_type == "agecomp",
    truth_time_step == "yearly"
  ) |>
  tidyr::unnest(cols = c(truth_om)) |>
  dplyr::mutate(
    truth_value = truth_value * weight_scalar,
    truth_unit = "mt"
  )

# Extract and unnest annual catch-at-age in numbers
catch_agecomp_om <- truth_om |>
  dplyr::filter(
    truth_label == "catch",
    truth_type == "agecomp",
    truth_time_step == "yearly"
  ) |>
  tidyr::unnest(cols = c(truth_om)) |>
  dplyr::mutate(
    truth_value = truth_value * biomass_scalar,
    truth_unit = "mt"
  ) |>
  dplyr::left_join(
    weight_agecomp_om |>
      dplyr::select(-species_name, -truth_label, -truth_type, -truth_time_step, -truth_unit),
    by = c("truth_year", "truth_group"),
    suffix = c("_catch", "_weight")
  ) |>
  dplyr::mutate(
    truth_value = ceiling(truth_value_catch / truth_value_weight),
    truth_unit = "numbers"
  ) |>
  dplyr::select(-truth_value_catch, -truth_value_weight)

# Extract and unnest annual biomass
biomass_index_om <- truth_om |>
  dplyr::filter(
    truth_label == "biomass",
    truth_type == "index",
    truth_time_step == "yearly"
  ) |>
  tidyr::unnest(cols = c(truth_om)) |>
  dplyr::mutate(
    truth_value = truth_value * biomass_scalar,
    truth_unit = "mt"
  )

# Extract and unnest annual number-at-age
number_agecomp_om <- truth_om |>
  dplyr::filter(
    truth_label == "numbers",
    truth_type == "agecomp",
    truth_time_step == "yearly"
  ) |>
  tidyr::unnest(cols = c(truth_om)) |>
  dplyr::mutate(
    truth_value = ceiling(truth_value * biomass_scalar / weight_scalar),
    truth_unit = "numbers"
  )

# Extract and unnest annual natural mortality by age
natural_mortality_agecomp_om <- truth_om |>
  dplyr::filter(
    truth_label == "natural_mortality",
    truth_type == "agecomp",
    truth_time_step == "yearly"
  ) |>
  tidyr::unnest(cols = c(truth_om))

# Extract and unnest annual fishing mortality by age
fishing_mortality_agecomp_om <- truth_om |>
  dplyr::filter(
    truth_label == "fishing_mortality",
    truth_type == "agecomp",
    truth_time_step == "yearly"
  ) |>
  tidyr::unnest(cols = c(truth_om))

# Extract and unnest annual fishing mortality: apical F
fishing_mortality_index_om <- truth_om |>
  dplyr::filter(
    truth_label == "fishing_mortality",
    truth_type == "index",
    truth_time_step == "yearly"
  ) |>
  tidyr::unnest(cols = c(truth_om))

Generate Sampled Data

To mimic observed fisheries data, sampled observations are generated from the OM “truth” while incorporating observation error.

Fishery-Dependent Data

Observed catch data are simulated by applying lognormal observation error to the “true” catch values with a standard deviation of 0.05. Age composition data are generated using a multinomial sampling distribution with an effective sample size of N=100.

catch_index_sd <- 0.05
catch_index_sampled <- catch_index_om |>
  dplyr::mutate(
    sampled_value = sample_lognormal(
      x = truth_value,
      sd = catch_index_sd
    )
  )

catch_index_sampled |>
  scroll_table()
species_name truth_label truth_type truth_time_step truth_year truth_unit truth_value sampled_value
menhaden catch index yearly 1985 mt 16436.46 15454.48
menhaden catch index yearly 1986 mt 16565.34 16775.75
menhaden catch index yearly 1987 mt 15939.05 16806.13
menhaden catch index yearly 1988 mt 12596.12 11188.14
menhaden catch index yearly 1989 mt 25993.96 26524.54
menhaden catch index yearly 1990 mt 321014.86 328829.77
menhaden catch index yearly 1991 mt 258893.40 251245.21
menhaden catch index yearly 1992 mt 365211.37 354920.81
menhaden catch index yearly 1993 mt 600358.51 582922.58
menhaden catch index yearly 1994 mt 659307.57 629822.64
menhaden catch index yearly 1995 mt 604887.34 589887.95
menhaden catch index yearly 1996 mt 907276.10 862019.15
menhaden catch index yearly 1997 mt 771183.60 740898.60
menhaden catch index yearly 1998 mt 878034.15 879768.17
menhaden catch index yearly 1999 mt 981962.22 1028932.91
menhaden catch index yearly 2000 mt 961678.94 955195.83
menhaden catch index yearly 2001 mt 926563.53 902060.99
menhaden catch index yearly 2002 mt 933937.94 891227.94
menhaden catch index yearly 2003 mt 435965.57 417571.04
menhaden catch index yearly 2004 mt 292324.12 329443.53
menhaden catch index yearly 2005 mt 66979.80 67346.13
menhaden catch index yearly 2006 mt 58767.23 57271.33
menhaden catch index yearly 2007 mt 36368.17 35531.40
menhaden catch index yearly 2008 mt 41439.10 42349.40
menhaden catch index yearly 2009 mt 42480.31 40980.84
menhaden catch index yearly 2010 mt 42963.63 39912.67
menhaden catch index yearly 2011 mt 47277.22 48594.79
menhaden catch index yearly 2012 mt 91043.37 86392.70
menhaden catch index yearly 2013 mt 87008.47 86834.03
menhaden catch index yearly 2014 mt 120764.99 115099.74
menhaden catch index yearly 2015 mt 119770.21 126398.53
menhaden catch index yearly 2016 mt 110616.90 107882.56
menhaden catch index yearly 2017 mt 175165.13 168849.39

catch_agecomp_sample_size <- 100
catch_agecomp_sampled <- catch_agecomp_om |>
  dplyr::group_by(truth_year) |>
  dplyr::mutate(
    sampled_value = sample_multinomial(
      x = truth_value,
      sample_size = catch_agecomp_sample_size
    )
  ) |>
  dplyr::ungroup()

Fishery-Independent Survey Data

There are two types of fishery-independent survey data considered: Young-of-Year (YOY, age-0) survey and a survey for ages 0-6+. The survey observations for ages 0-6+ are simulated by applying a logistic selectivity and catchability coefficient (q) to the “true” number-at-age matrix from the OM. Observed survey index is simulated by applying lognormal observation error to the “true” values with a standard deviation of 0.1. Age composition data are generated using a multinomial sampling distribution with an effective sample size of N=100.

ages <- 0:6
names(ages) <- functional_groups |>
  dplyr::filter(species == "menhaden") |>
  dplyr::pull(group)

# YOY survey for age-0
yoy_q <- 0.05
yoy_index_sd <- 0.1
yoy_selectivity <- c(1, 0, 0, 0, 0, 0, 0)
names(yoy_selectivity) <- functional_groups |>
  dplyr::filter(species == "menhaden") |>
  dplyr::pull(group)
yoy_index_sampled <- number_agecomp_om |>
  dplyr::left_join(
    weight_agecomp_om |>
      dplyr::select(-species_name, -truth_label, -truth_type, -truth_time_step, -truth_unit),
    by = c("truth_year", "truth_group"),
    suffix = c("_number", "_weight")
  ) |>
  dplyr::filter(truth_group == "0") |>
  dplyr::mutate(
    truth_value_selected_number = ceiling(truth_value_number * yoy_q),
    truth_value_selected_biomass = truth_value_selected_number * truth_value_weight,
    sampled_value = sample_lognormal(
      x = truth_value_selected_biomass,
      sd = yoy_index_sd
    )
  ) |>
  dplyr::select(
    -truth_value_number, -truth_value_weight,
    -truth_value_selected_number, -truth_value_selected_biomass
  ) |>
  dplyr::mutate(
    species_name = "menhaden",
    truth_label = "biomass",
    truth_type = "index",
    truth_time_step = "yearly",
    truth_unit = "mt"
  )
yoy_inflection_point_asc <- -1.0
yoy_slope_asc <- 10
yoy_inflection_point_desc <- 0.5
yoy_slope_desc <- 10
yoy_selectivity_ascending  <- 1 / (1 + exp(-yoy_slope_asc * (ages - yoy_inflection_point_asc)))
yoy_selectivity_descending <- 1 / (1 + exp(-yoy_slope_desc * (ages - yoy_inflection_point_desc)))
yoy_selectivity <- yoy_selectivity_ascending * (1 - yoy_selectivity_descending)

# Survey for ages 0-6+
# Define explicit survey catchability
catchability_survey <- 0.05
# Define logistic selectivity parameters using values from BAM NAD survey
selectivity_inflection_point <- 3.03
selectivity_slope <- 2.2
selectivity_survey <- 1 / (1 + exp(-selectivity_slope * (ages - selectivity_inflection_point)))

names(selectivity_survey) <- functional_groups |>
  dplyr::filter(species == "menhaden") |>
  dplyr::pull(group)

# Survey index
survey_data <- number_agecomp_om |>
  dplyr::left_join(
    weight_agecomp_om |>
      dplyr::select(-species_name, -truth_label, -truth_type, -truth_time_step, -truth_unit),
    by = c("truth_year", "truth_group"),
    suffix = c("_number", "_weight")
  ) |>
  dplyr::mutate(
    selectivity = selectivity_survey[truth_group],
    truth_value_selected_number = ceiling(truth_value_number * selectivity * catchability_survey),
    truth_value_selected_biomass = truth_value_selected_number * truth_value_weight
  )

# Generate observed survey biomass indices with lognormal error (SD = 0.1)
survey_index_sd <- 0.1
survey_index_sampled <- survey_data |>
  dplyr::select(
    -truth_value_number, -truth_value_weight, -selectivity, -truth_value_selected_number
  ) |>
  dplyr::mutate(
    truth_label = "biomass",
    truth_unit = "mt"
  ) |>
  # Aggregate all ages/groups into one annual value
  dplyr::group_by(truth_year) |>
  dplyr::summarise(
    truth_value = sum(truth_value_selected_biomass),
    .groups = "drop"
  ) |>
  dplyr::mutate(
    species_name = "menhaden",
    truth_label = "biomass",
    truth_type = "index",
    truth_time_step = "yearly",
    truth_unit = "mt"
  ) |>
  dplyr::mutate(
    sampled_value = sample_lognormal(
      x = truth_value,
      sd = survey_index_sd
    )
  )

# Survey agecomp
survey_agecomp_sample_size <- 100
survey_agecomp_sampled <- survey_data |>
  dplyr::group_by(truth_year) |>
  dplyr::mutate(
    sampled_value = sample_multinomial(
      x = truth_value_selected_number,
      sample_size = survey_agecomp_sample_size
    )
  ) |>
  dplyr::ungroup() |>
  dplyr::select(
    -truth_value_number, -truth_value_weight, -selectivity,
    -truth_value_selected_biomass
  ) |>
  dplyr::rename(truth_value = truth_value_selected_number)

Prepare FIMS-compatible data

The sampled fishery-dependent and fishery-independent observations are next reformatted into a FIMSFrame object for use with the FIMS. This includes annual landings, survey biomass indices, age composition observations, and weight-at-age information.

The resulting FIMSFrame object provides the standardized data structure required for model configuration and estimation in FIMS.

Click to expand/collapse code
fishing_fleet_name <- "fishing_fleet"
survey_fleet_name <- "survey_fleet"
yoy_fleet_name <- "yoy_fleet"

catch_data <- data.frame(
  type = "catch",
  fleet = fishing_fleet_name,
  age = NA,
  timing = model_years,
  observed = catch_index_sampled[["sampled_value"]],
  unit = "mt",
  uncertainty = paste(
    "~ dlnorm(meanlog = log_catch_expected, sdlog =",
    catch_index_sd,
    ")"
  )
)

index_data <- rbind(
  data.frame(
    type = "index",
    fleet = yoy_fleet_name,
    age = NA,
    timing = model_years,
    observed = yoy_index_sampled[["sampled_value"]],
    unit = "mt",
    uncertainty = paste(
      "~ dlnorm(meanlog = log_index_expected, sdlog =",
      yoy_index_sd,
      ")"
    )
  ),
  data.frame(
    type = "index",
    fleet = survey_fleet_name,
    age = NA,
    timing = model_years,
    observed = survey_index_sampled[["sampled_value"]],
    unit = "mt",
    uncertainty = paste(
      "~ dlnorm(meanlog = log_index_expected, sdlog =",
      survey_index_sd,
      ")"
    )
  )
)

age_data <- rbind(
  data.frame(
    type = "age_comp",
    fleet = fishing_fleet_name,
    age = unname(ages[catch_agecomp_sampled[["truth_group"]]]),
    timing = catch_agecomp_sampled[["truth_year"]],
    observed = catch_agecomp_sampled[["sampled_value"]],
    unit = "number",
    uncertainty = paste(
      "~ dmultinom(prob = agecomp_proportion, size =",
      catch_agecomp_sample_size,
      ")"
    )
  ),
  data.frame(
    type = "age_comp",
    fleet = survey_fleet_name,
    age = unname(ages[survey_agecomp_sampled[["truth_group"]]]),
    timing = survey_agecomp_sampled[["truth_year"]],
    observed = survey_agecomp_sampled[["sampled_value"]],
    unit = "number",
    uncertainty = paste(
      "~ dmultinom(prob = agecomp_proportion, size =",
      survey_agecomp_sample_size,
      ")"
    )
  )
)

weight_at_age <- data.frame(
  type = "weight_at_age",
  fleet = fishing_fleet_name,
  age = unname(ages[weight_agecomp_om[["truth_group"]]]),
  timing = weight_agecomp_om[["truth_year"]],
  observed = weight_agecomp_om[["truth_value"]],
  unit = "mt",
  uncertainty = NA
)

weight_year_plus <- weight_at_age |>
  dplyr::filter(timing == max(model_years)) |>
  dplyr::mutate(timing = timing + 1)

weight_at_age_data <- dplyr::bind_rows(
  weight_at_age,
  weight_year_plus
)

data_fims <- rbind(catch_data, index_data, age_data, weight_at_age_data) |>
  dplyr::mutate(
    length = NA,
    .after = "age"
  ) |>
  FIMS::FIMSFrame()

methods::show(data_fims)
#> # A tibble: 6 × 8
#>   type     fleet           age length timing observed unit   uncertainty
#>   <chr>    <chr>         <int>  <dbl>  <dbl>    <dbl> <chr>  <chr>
#> 1 age_comp fishing_fleet     0     NA   1985       14 number ~ dmultinom(prob =…
#> 2 age_comp fishing_fleet     1     NA   1985       34 number ~ dmultinom(prob =…
#> 3 age_comp fishing_fleet     2     NA   1985       44 number ~ dmultinom(prob =…
#> 4 age_comp fishing_fleet     3     NA   1985        8 number ~ dmultinom(prob =…
#> 5 age_comp fishing_fleet     4     NA   1985        0 number ~ dmultinom(prob =…
#> 6 age_comp fishing_fleet     5     NA   1985        0 number ~ dmultinom(prob =…
#> additional slots include the following:fleets:
#> [1] "fishing_fleet" "yoy_fleet"     "survey_fleet"
#> n_years:
#> [1] 33
#> ages:
#> [1] 0 1 2 3 4 5 6
#> n_ages:
#> [1] 7
#> lengths:
#> numeric(0)
#> n_lengths:
#> [1] 0
#> start_year:
#> [1] 1985
#> end_year:
#> [1] 2017

Configure the FIMS estimation model

FIMS models are initialized using a set of default configurations and parameter values derived from the input data. In this section, we customize those defaults to better align the FIMS estimation model with the underlying ecosystem OM.

Key modifications include:

  • Replacing the default selectivity formulation with a double-logistic selectivity function for both the fishing fleet and survey fleet.
  • Initializing fishing mortality, survey catchability, recruitment, and natural mortality parameters using values derived from the OM “truth”.
  • Specifying maturity-at-age using a logistic maturity curve.
  • Initializing numbers-at-age in the first model year directly from the OM population state.

These steps provide informed starting values that improve consistency between the OM and the estimation model.

Click to expand/collapse code
# Create default parameter values from the updated model configuration
default_parameters <- FIMS::setup_default_parameters(data = data_fims)

# Fishing fleet selectivity
# Explicit fishing fleet selectivity parameter values from OM
catch_selectivity_inflection_point_asc <- 1.5
catch_selectivity_slope_asc <- 2.0
catch_selectivity_inflection_point_desc <- 4.0
catch_selectivity_slope_desc <- 1.5

# Alternative option: Estimate selectivity from OM fishing mortality-at-age
# Mismatch note: the ecosystem model OM scales fishing selectivity (double
# logistic) to a maximum of 1, where FIMS does not.
catch_selectivity <- estimate_true_selectivity(
  data = fishing_mortality_agecomp_om,
  ages = ages,
  functional_form = "double_logistic"
) |>
  dplyr::mutate(fleet_name = fishing_fleet_name)

# Define selectivity updates for each fleet
selectivity_temp <- FIMS::setup_default_Selectivity(
  data = data_fims,
  fleet = fishing_fleet_name,
  module_type = "DoubleLogistic"
)

selectivity_fishing_fleet <- selectivity_temp |>
  dplyr::mutate(fleet = fishing_fleet_name) |>
  dplyr::rows_update(
    y = tibble::tibble(
      fleet = fishing_fleet_name,
      label = c(
        "inflection_point_asc",
        "slope_asc",
        "inflection_point_desc",
        "slope_desc"
      ),
      value = c(
        catch_selectivity_inflection_point_asc,
        catch_selectivity_slope_asc,
        catch_selectivity_inflection_point_desc,
        catch_selectivity_slope_desc
      )
    ),
    by = c("fleet", "label")
  )

selectivity_yoy_fleet <- selectivity_temp |>
  dplyr::mutate(fleet = yoy_fleet_name) |>
  dplyr::rows_update(
    y = tibble::tibble(
      fleet = yoy_fleet_name,
      label = c(
        "inflection_point_asc",
        "slope_asc",
        "inflection_point_desc",
        "slope_desc"
      ),
      estimation_type = "constant",
      value = c(
        yoy_inflection_point_asc,
        yoy_slope_asc,
        yoy_inflection_point_desc,
        yoy_slope_desc
      )
    ),
    by = c("fleet", "label")
  )

selectivity_survey_fleet <- FIMS::setup_default_Selectivity(
  data = data_fims,
  fleet = survey_fleet_name,
  module_type = "Logistic"
) |>
  dplyr::rows_update(
    y = tibble::tibble(
      fleet = survey_fleet_name,
      label = c("inflection_point", "slope"),
      value = c(
        selectivity_inflection_point,
        selectivity_slope
      )
    ),
    by = c("fleet", "label")
  )

# Estimate maturity parameters
maturity_parameters <- ecosystemom::estimate_true_maturity(
  ages = ages,
  spawning_proportion = c(0, 0.1, 0.5, 0.9, 1, 1, 1),
  functional_form = "logistic"
)

# Estimate recruitment log_sd
recruitment_ewe <- number_agecomp_om |>
  dplyr::filter(truth_group == "0", truth_year != model_years[1]) |>
  dplyr::pull(truth_value)

log_sd_proxy <- (sd(log(recruitment_ewe) - mean(log(recruitment_ewe)))) |>
 log()

# Update parameter values using OM-derived truth information
updated_parameters <- default_parameters |>
  dplyr::filter(
    !(fleet %in% c(
      fishing_fleet_name,
      survey_fleet_name,
      yoy_fleet_name
    ) & module_name == "Selectivity")
  ) |>
  dplyr::bind_rows(
    selectivity_fishing_fleet,
    selectivity_survey_fleet,
    selectivity_yoy_fleet
  ) |>
  dplyr::rows_update(
    y = tibble::tibble(
      fleet = fishing_fleet_name,
      label = "log_Fmort",
      timing = fishing_mortality_index_om[["truth_year"]],
      value = fishing_mortality_index_om[["truth_value"]] |>
        log()
    ),
    by = c("fleet", "label", "timing")
  ) |>
  dplyr::rows_update(
    y = tibble::tibble(
      fleet = survey_fleet_name,
      label = c("log_q"),
      estimation_type = "fixed_effects",
      value = log(catchability_survey)
    ),
    by = c("fleet", "label")
  )  |>
  dplyr::rows_update(
    y = tibble::tibble(
      fleet = yoy_fleet_name,
      label = "log_q",
      estimation_type = "fixed_effects",
      value = log(yoy_q)
    ),
    by = c("fleet", "label")
  ) |>
  dplyr::rows_update(
    y = tibble::tibble(
      label = "log_rzero",
      module_type = "BevertonHolt",
      value = number_agecomp_om |>
        dplyr::filter(truth_group == "0") |>
        dplyr::pull(truth_value) |>
        mean() |>
        log()
    ),
    by = c("label", "module_type")
  ) |>
  dplyr::rows_update(
    y = tibble::tibble(
      label = "logit_steep",
      module_type = "BevertonHolt",
      # calculate from vulnerability matrix: v / (v + 1)
      # v = 411.23 + 1.02 + 191.58 + 2 + 1016.36 + 12.18 + 2 + 403.26 = 2039.63
      # h = v / (v + 1) = 0.99
      value = -log(1.0 - 0.99) + log(0.99 - 0.2)
    ),
    by = c("label", "module_type")
  ) |>
  dplyr::rows_update(
    y = tibble::tibble(
      label = "log_sd",
      module_type = "BevertonHolt",
      # estimation_type = "constant",
      value = log_sd_proxy
    ),
    by = c("label", "module_type")
  ) |>
  dplyr::rows_update(
    y = tibble::tibble(
      label = "log_devs",
      estimation_type = "random_effects",
      module_type = "BevertonHolt"
    ),
    by = c("label", "module_type")
  ) |>
  dplyr::filter(!(module_name == "Maturity")) |>
  dplyr::bind_rows(maturity_parameters) |>
  dplyr::rows_update(
    y = tibble::tibble(
      label = "log_M",
      age = unname(ages[natural_mortality_agecomp_om[["truth_group"]]]),
      timing = natural_mortality_agecomp_om[["truth_year"]],
      value = log(natural_mortality_agecomp_om[["truth_value"]])
    ),
    by = c("label", "age", "timing")
  ) |>
  dplyr::rows_update(
    y = tibble::tibble(
      label = "log_init_naa",
      age = number_agecomp_om |>
        dplyr::filter(truth_year == model_years[1]) |>
        dplyr::pull(truth_group) |>
        (\(x) unname(ages[x]))(),
      value = number_agecomp_om |>
        dplyr::filter(truth_year == model_years[1]) |>
        dplyr::pull(truth_value) |>
        log()
    ),
    by = c("label", "age")
  )

# Display updated parameter table
updated_parameters |>
  scroll_table()
module_name fleet module_type label age length timing value estimation_type distribution_type distribution model_family fleet_name time
Fleet fishing_fleet NA log_q NA NA NA 0.0000000 constant NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 1985 -3.8169883 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 1986 -3.8642773 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 1987 -3.9372260 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 1988 -4.1905182 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 1989 -3.4501902 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 1990 -0.7618935 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 1991 -0.9300768 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 1992 -0.5149073 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 1993 0.1108822 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 1994 0.2746387 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 1995 0.1974986 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 1996 0.8686825 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 1997 0.7605371 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 1998 1.0595592 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 1999 1.4608235 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2000 1.7343581 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2001 2.1221046 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2002 3.4091536 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2003 2.7836491 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2004 4.0693693 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2005 1.8253162 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2006 1.8235547 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2007 1.3159119 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2008 0.9977561 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2009 0.8308129 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2010 0.4891866 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2011 0.0541915 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2012 0.4921106 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2013 -0.0429996 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2014 -0.1234679 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2015 -0.5121933 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2016 -0.9892749 fixed_effects NA NA NA NA NA
Fleet fishing_fleet NA log_Fmort NA NA 2017 -0.7978597 fixed_effects NA NA NA NA NA
Fleet yoy_fleet NA log_q NA NA NA -2.9957323 fixed_effects NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 1985 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 1986 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 1987 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 1988 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 1989 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 1990 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 1991 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 1992 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 1993 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 1994 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 1995 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 1996 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 1997 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 1998 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 1999 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2000 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2001 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2002 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2003 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2004 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2005 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2006 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2007 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2008 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2009 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2010 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2011 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2012 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2013 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2014 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2015 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2016 -200.0000000 constant NA NA NA NA NA
Fleet yoy_fleet NA log_Fmort NA NA 2017 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_q NA NA NA -2.9957323 fixed_effects NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 1985 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 1986 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 1987 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 1988 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 1989 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 1990 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 1991 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 1992 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 1993 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 1994 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 1995 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 1996 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 1997 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 1998 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 1999 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2000 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2001 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2002 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2003 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2004 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2005 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2006 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2007 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2008 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2009 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2010 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2011 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2012 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2013 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2014 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2015 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2016 -200.0000000 constant NA NA NA NA NA
Fleet survey_fleet NA log_Fmort NA NA 2017 -200.0000000 constant NA NA NA NA NA
Recruitment NA BevertonHolt log_rzero NA NA NA 25.0198225 fixed_effects NA NA NA NA NA
Recruitment NA BevertonHolt logit_steep NA NA NA 4.3694479 constant NA NA NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 1986 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 1987 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 1988 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 1989 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 1990 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 1991 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 1992 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 1993 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 1994 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 1995 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 1996 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 1997 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 1998 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 1999 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2000 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2001 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2002 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2003 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2004 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2005 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2006 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2007 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2008 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2009 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2010 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2011 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2012 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2013 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2014 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2015 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2016 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_devs NA NA 2017 0.0000000 random_effects process Dnorm NA NA NA
Recruitment NA BevertonHolt log_sd NA NA NA 0.3346432 fixed_effects process Dnorm NA NA NA
Growth NA EWAA NA NA NA NA NA NA NA NA NA NA NA
Population NA NA log_M 0 NA 1985 0.5508998 constant NA NA NA NA NA
Population NA NA log_M 1 NA 1985 0.2560636 constant NA NA NA NA NA
Population NA NA log_M 2 NA 1985 0.2269559 constant NA NA NA NA NA
Population NA NA log_M 3 NA 1985 0.3110443 constant NA NA NA NA NA
Population NA NA log_M 4 NA 1985 -0.0236712 constant NA NA NA NA NA
Population NA NA log_M 5 NA 1985 -0.0597589 constant NA NA NA NA NA
Population NA NA log_M 6 NA 1985 -0.3372217 constant NA NA NA NA NA
Population NA NA log_M 0 NA 1986 0.5496808 constant NA NA NA NA NA
Population NA NA log_M 1 NA 1986 0.2508207 constant NA NA NA NA NA
Population NA NA log_M 2 NA 1986 0.2295923 constant NA NA NA NA NA
Population NA NA log_M 3 NA 1986 0.3175522 constant NA NA NA NA NA
Population NA NA log_M 4 NA 1986 -0.0190588 constant NA NA NA NA NA
Population NA NA log_M 5 NA 1986 -0.0485796 constant NA NA NA NA NA
Population NA NA log_M 6 NA 1986 -0.3382070 constant NA NA NA NA NA
Population NA NA log_M 0 NA 1987 0.5428116 constant NA NA NA NA NA
Population NA NA log_M 1 NA 1987 0.2516196 constant NA NA NA NA NA
Population NA NA log_M 2 NA 1987 0.2243271 constant NA NA NA NA NA
Population NA NA log_M 3 NA 1987 0.3219036 constant NA NA NA NA NA
Population NA NA log_M 4 NA 1987 -0.0153254 constant NA NA NA NA NA
Population NA NA log_M 5 NA 1987 -0.0467707 constant NA NA NA NA NA
Population NA NA log_M 6 NA 1987 -0.3333317 constant NA NA NA NA NA
Population NA NA log_M 0 NA 1988 0.5341748 constant NA NA NA NA NA
Population NA NA log_M 1 NA 1988 0.2521186 constant NA NA NA NA NA
Population NA NA log_M 2 NA 1988 0.2281861 constant NA NA NA NA NA
Population NA NA log_M 3 NA 1988 0.3208784 constant NA NA NA NA NA
Population NA NA log_M 4 NA 1988 -0.0106176 constant NA NA NA NA NA
Population NA NA log_M 5 NA 1988 -0.0400228 constant NA NA NA NA NA
Population NA NA log_M 6 NA 1988 -0.3248923 constant NA NA NA NA NA
Population NA NA log_M 0 NA 1989 0.5297394 constant NA NA NA NA NA
Population NA NA log_M 1 NA 1989 0.2523541 constant NA NA NA NA NA
Population NA NA log_M 2 NA 1989 0.2249322 constant NA NA NA NA NA
Population NA NA log_M 3 NA 1989 0.3219177 constant NA NA NA NA NA
Population NA NA log_M 4 NA 1989 -0.0117210 constant NA NA NA NA NA
Population NA NA log_M 5 NA 1989 -0.0300811 constant NA NA NA NA NA
Population NA NA log_M 6 NA 1989 -0.3067628 constant NA NA NA NA NA
Population NA NA log_M 0 NA 1990 0.5218437 constant NA NA NA NA NA
Population NA NA log_M 1 NA 1990 0.2207501 constant NA NA NA NA NA
Population NA NA log_M 2 NA 1990 0.0524649 constant NA NA NA NA NA
Population NA NA log_M 3 NA 1990 0.2237227 constant NA NA NA NA NA
Population NA NA log_M 4 NA 1990 -0.0403748 constant NA NA NA NA NA
Population NA NA log_M 5 NA 1990 -0.0343346 constant NA NA NA NA NA
Population NA NA log_M 6 NA 1990 -0.2839056 constant NA NA NA NA NA
Population NA NA log_M 0 NA 1991 0.5219444 constant NA NA NA NA NA
Population NA NA log_M 1 NA 1991 0.2222651 constant NA NA NA NA NA
Population NA NA log_M 2 NA 1991 0.0783603 constant NA NA NA NA NA
Population NA NA log_M 3 NA 1991 0.2346930 constant NA NA NA NA NA
Population NA NA log_M 4 NA 1991 -0.0292855 constant NA NA NA NA NA
Population NA NA log_M 5 NA 1991 -0.0147846 constant NA NA NA NA NA
Population NA NA log_M 6 NA 1991 -0.2561862 constant NA NA NA NA NA
Population NA NA log_M 0 NA 1992 0.5451271 constant NA NA NA NA NA
Population NA NA log_M 1 NA 1992 0.2045124 constant NA NA NA NA NA
Population NA NA log_M 2 NA 1992 -0.0236257 constant NA NA NA NA NA
Population NA NA log_M 3 NA 1992 0.1792416 constant NA NA NA NA NA
Population NA NA log_M 4 NA 1992 -0.0482799 constant NA NA NA NA NA
Population NA NA log_M 5 NA 1992 -0.0099634 constant NA NA NA NA NA
Population NA NA log_M 6 NA 1992 -0.2311984 constant NA NA NA NA NA
Population NA NA log_M 0 NA 1993 0.5610290 constant NA NA NA NA NA
Population NA NA log_M 1 NA 1993 0.1734259 constant NA NA NA NA NA
Population NA NA log_M 2 NA 1993 -0.3884473 constant NA NA NA NA NA
Population NA NA log_M 3 NA 1993 0.0164101 constant NA NA NA NA NA
Population NA NA log_M 4 NA 1993 -0.0946253 constant NA NA NA NA NA
Population NA NA log_M 5 NA 1993 -0.0237609 constant NA NA NA NA NA
Population NA NA log_M 6 NA 1993 -0.2152818 constant NA NA NA NA NA
Population NA NA log_M 0 NA 1994 0.5657686 constant NA NA NA NA NA
Population NA NA log_M 1 NA 1994 0.1637459 constant NA NA NA NA NA
Population NA NA log_M 2 NA 1994 -0.5861205 constant NA NA NA NA NA
Population NA NA log_M 3 NA 1994 -0.0714478 constant NA NA NA NA NA
Population NA NA log_M 4 NA 1994 -0.1141957 constant NA NA NA NA NA
Population NA NA log_M 5 NA 1994 -0.0258254 constant NA NA NA NA NA
Population NA NA log_M 6 NA 1994 -0.2067673 constant NA NA NA NA NA
Population NA NA log_M 0 NA 1995 0.5644054 constant NA NA NA NA NA
Population NA NA log_M 1 NA 1995 0.1731782 constant NA NA NA NA NA
Population NA NA log_M 2 NA 1995 -0.4822289 constant NA NA NA NA NA
Population NA NA log_M 3 NA 1995 -0.0402337 constant NA NA NA NA NA
Population NA NA log_M 4 NA 1995 -0.1166504 constant NA NA NA NA NA
Population NA NA log_M 5 NA 1995 -0.0238560 constant NA NA NA NA NA
Population NA NA log_M 6 NA 1995 -0.2018829 constant NA NA NA NA NA
Population NA NA log_M 0 NA 1996 0.5616368 constant NA NA NA NA NA
Population NA NA log_M 1 NA 1996 0.0927194 constant NA NA NA NA NA
Population NA NA log_M 2 NA 1996 -Inf constant NA NA NA NA NA
Population NA NA log_M 3 NA 1996 -0.5930435 constant NA NA NA NA NA
Population NA NA log_M 4 NA 1996 -0.2263619 constant NA NA NA NA NA
Population NA NA log_M 5 NA 1996 -0.0633711 constant NA NA NA NA NA
Population NA NA log_M 6 NA 1996 -0.2110095 constant NA NA NA NA NA
Population NA NA log_M 0 NA 1997 0.5569490 constant NA NA NA NA NA
Population NA NA log_M 1 NA 1997 0.1085831 constant NA NA NA NA NA
Population NA NA log_M 2 NA 1997 -4.1049463 constant NA NA NA NA NA
Population NA NA log_M 3 NA 1997 -0.4744604 constant NA NA NA NA NA
Population NA NA log_M 4 NA 1997 -0.1958205 constant NA NA NA NA NA
Population NA NA log_M 5 NA 1997 -0.0517913 constant NA NA NA NA NA
Population NA NA log_M 6 NA 1997 -0.2105887 constant NA NA NA NA NA
Population NA NA log_M 0 NA 1998 0.5479546 constant NA NA NA NA NA
Population NA NA log_M 1 NA 1998 0.0572228 constant NA NA NA NA NA
Population NA NA log_M 2 NA 1998 -Inf constant NA NA NA NA NA
Population NA NA log_M 3 NA 1998 -1.0690338 constant NA NA NA NA NA
Population NA NA log_M 4 NA 1998 -0.2810005 constant NA NA NA NA NA
Population NA NA log_M 5 NA 1998 -0.0664402 constant NA NA NA NA NA
Population NA NA log_M 6 NA 1998 -0.2185964 constant NA NA NA NA NA
Population NA NA log_M 0 NA 1999 0.5327931 constant NA NA NA NA NA
Population NA NA log_M 1 NA 1999 -0.0441674 constant NA NA NA NA NA
Population NA NA log_M 2 NA 1999 -Inf constant NA NA NA NA NA
Population NA NA log_M 3 NA 1999 -Inf constant NA NA NA NA NA
Population NA NA log_M 4 NA 1999 -0.4498587 constant NA NA NA NA NA
Population NA NA log_M 5 NA 1999 -0.1215095 constant NA NA NA NA NA
Population NA NA log_M 6 NA 1999 -0.2372542 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2000 0.5113236 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2000 -0.1470226 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2000 -Inf constant NA NA NA NA NA
Population NA NA log_M 3 NA 2000 -Inf constant NA NA NA NA NA
Population NA NA log_M 4 NA 2000 -0.6245267 constant NA NA NA NA NA
Population NA NA log_M 5 NA 2000 -0.1645632 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2000 -0.2643578 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2001 0.4796376 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2001 -0.3673947 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2001 -Inf constant NA NA NA NA NA
Population NA NA log_M 3 NA 2001 -Inf constant NA NA NA NA NA
Population NA NA log_M 4 NA 2001 -1.1266837 constant NA NA NA NA NA
Population NA NA log_M 5 NA 2001 -0.2254867 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2001 -0.2999345 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2002 0.4397803 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2002 -Inf constant NA NA NA NA NA
Population NA NA log_M 2 NA 2002 -Inf constant NA NA NA NA NA
Population NA NA log_M 3 NA 2002 -Inf constant NA NA NA NA NA
Population NA NA log_M 4 NA 2002 -Inf constant NA NA NA NA NA
Population NA NA log_M 5 NA 2002 -0.7602306 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2002 -0.4364630 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2003 0.4277689 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2003 -1.6438935 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2003 -Inf constant NA NA NA NA NA
Population NA NA log_M 3 NA 2003 -Inf constant NA NA NA NA NA
Population NA NA log_M 4 NA 2003 -Inf constant NA NA NA NA NA
Population NA NA log_M 5 NA 2003 -0.3667872 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2003 -0.4059875 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2004 0.3493646 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2004 -Inf constant NA NA NA NA NA
Population NA NA log_M 2 NA 2004 -Inf constant NA NA NA NA NA
Population NA NA log_M 3 NA 2004 -Inf constant NA NA NA NA NA
Population NA NA log_M 4 NA 2004 -Inf constant NA NA NA NA NA
Population NA NA log_M 5 NA 2004 -1.8653418 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2004 -0.6038265 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2005 0.4034368 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2005 -0.2478456 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2005 -Inf constant NA NA NA NA NA
Population NA NA log_M 3 NA 2005 -Inf constant NA NA NA NA NA
Population NA NA log_M 4 NA 2005 -0.9153687 constant NA NA NA NA NA
Population NA NA log_M 5 NA 2005 -0.1676329 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2005 -0.3864848 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2006 0.3040236 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2006 -0.1735341 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2006 -Inf constant NA NA NA NA NA
Population NA NA log_M 3 NA 2006 -Inf constant NA NA NA NA NA
Population NA NA log_M 4 NA 2006 -1.1602340 constant NA NA NA NA NA
Population NA NA log_M 5 NA 2006 -0.2616114 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2006 -0.3879695 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2007 0.3507546 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2007 -0.0869438 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2007 -Inf constant NA NA NA NA NA
Population NA NA log_M 3 NA 2007 -Inf constant NA NA NA NA NA
Population NA NA log_M 4 NA 2007 -0.6692146 constant NA NA NA NA NA
Population NA NA log_M 5 NA 2007 -0.4177943 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2007 -0.3769440 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2008 0.3440033 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2008 0.0348218 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2008 -Inf constant NA NA NA NA NA
Population NA NA log_M 3 NA 2008 -1.1451654 constant NA NA NA NA NA
Population NA NA log_M 4 NA 2008 -0.3393536 constant NA NA NA NA NA
Population NA NA log_M 5 NA 2008 -0.3474698 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2008 -0.3874613 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2009 0.3186062 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2009 0.0483931 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2009 -Inf constant NA NA NA NA NA
Population NA NA log_M 3 NA 2009 -0.7149624 constant NA NA NA NA NA
Population NA NA log_M 4 NA 2009 -0.3171876 constant NA NA NA NA NA
Population NA NA log_M 5 NA 2009 -0.1816523 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2009 -0.4668665 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2010 0.3385767 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2010 0.0772800 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2010 -1.2519046 constant NA NA NA NA NA
Population NA NA log_M 3 NA 2010 -0.2743273 constant NA NA NA NA NA
Population NA NA log_M 4 NA 2010 -0.2751204 constant NA NA NA NA NA
Population NA NA log_M 5 NA 2010 -0.1903012 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2010 -0.4565050 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2011 0.3385874 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2011 0.1347876 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2011 -0.4523701 constant NA NA NA NA NA
Population NA NA log_M 3 NA 2011 -0.0626161 constant NA NA NA NA NA
Population NA NA log_M 4 NA 2011 -0.1686106 constant NA NA NA NA NA
Population NA NA log_M 5 NA 2011 -0.1978452 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2011 -0.4505634 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2012 0.3402014 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2012 0.0846773 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2012 -1.1703863 constant NA NA NA NA NA
Population NA NA log_M 3 NA 2012 -0.2777501 constant NA NA NA NA NA
Population NA NA log_M 4 NA 2012 -0.2445654 constant NA NA NA NA NA
Population NA NA log_M 5 NA 2012 -0.1729029 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2012 -0.4788755 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2013 0.3675366 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2013 0.1375695 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2013 -0.3645117 constant NA NA NA NA NA
Population NA NA log_M 3 NA 2013 -0.0057998 constant NA NA NA NA NA
Population NA NA log_M 4 NA 2013 -0.1683496 constant NA NA NA NA NA
Population NA NA log_M 5 NA 2013 -0.1686942 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2013 -0.4504656 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2014 0.3728260 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2014 0.1541138 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2014 -0.2739337 constant NA NA NA NA NA
Population NA NA log_M 3 NA 2014 0.0110382 constant NA NA NA NA NA
Population NA NA log_M 4 NA 2014 -0.1547115 constant NA NA NA NA NA
Population NA NA log_M 5 NA 2014 -0.1590271 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2014 -0.4498478 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2015 0.3988552 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2015 0.1721650 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2015 -0.0775759 constant NA NA NA NA NA
Population NA NA log_M 3 NA 2015 0.1190144 constant NA NA NA NA NA
Population NA NA log_M 4 NA 2015 -0.1392285 constant NA NA NA NA NA
Population NA NA log_M 5 NA 2015 -0.1442547 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2015 -0.4431297 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2016 0.4354996 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2016 0.1969081 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2016 0.0442383 constant NA NA NA NA NA
Population NA NA log_M 3 NA 2016 0.1912707 constant NA NA NA NA NA
Population NA NA log_M 4 NA 2016 -0.1018778 constant NA NA NA NA NA
Population NA NA log_M 5 NA 2016 -0.1467134 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2016 -0.4330370 constant NA NA NA NA NA
Population NA NA log_M 0 NA 2017 0.4713429 constant NA NA NA NA NA
Population NA NA log_M 1 NA 2017 0.1997606 constant NA NA NA NA NA
Population NA NA log_M 2 NA 2017 0.0200169 constant NA NA NA NA NA
Population NA NA log_M 3 NA 2017 0.1782819 constant NA NA NA NA NA
Population NA NA log_M 4 NA 2017 -0.0977768 constant NA NA NA NA NA
Population NA NA log_M 5 NA 2017 -0.1300917 constant NA NA NA NA NA
Population NA NA log_M 6 NA 2017 -0.4349059 constant NA NA NA NA NA
Population NA NA log_init_naa 0 NA NA 25.6734991 fixed_effects NA NA NA NA NA
Population NA NA log_init_naa 1 NA NA 24.0293124 fixed_effects NA NA NA NA NA
Population NA NA log_init_naa 2 NA NA 22.6669292 fixed_effects NA NA NA NA NA
Population NA NA log_init_naa 3 NA NA 21.1789255 fixed_effects NA NA NA NA NA
Population NA NA log_init_naa 4 NA NA 19.7488152 fixed_effects NA NA NA NA NA
Population NA NA log_init_naa 5 NA NA 18.5119285 fixed_effects NA NA NA NA NA
Population NA NA log_init_naa 6 NA NA 17.9557101 fixed_effects NA NA NA NA NA
Population NA NA proportion_female NA NA NA 0.5000000 constant NA NA NA NA NA
Selectivity fishing_fleet DoubleLogistic inflection_point_asc NA NA NA 1.5000000 fixed_effects NA NA NA NA NA
Selectivity fishing_fleet DoubleLogistic slope_asc NA NA NA 2.0000000 fixed_effects NA NA NA NA NA
Selectivity fishing_fleet DoubleLogistic inflection_point_desc NA NA NA 4.0000000 fixed_effects NA NA NA NA NA
Selectivity fishing_fleet DoubleLogistic slope_desc NA NA NA 1.5000000 fixed_effects NA NA NA NA NA
Selectivity survey_fleet Logistic inflection_point NA NA NA 3.0300000 fixed_effects NA NA NA NA NA
Selectivity survey_fleet Logistic slope NA NA NA 2.2000000 fixed_effects NA NA NA NA NA
Selectivity yoy_fleet DoubleLogistic inflection_point_asc NA NA NA -1.0000000 constant NA NA NA NA NA
Selectivity yoy_fleet DoubleLogistic slope_asc NA NA NA 10.0000000 constant NA NA NA NA NA
Selectivity yoy_fleet DoubleLogistic inflection_point_desc NA NA NA 0.5000000 constant NA NA NA NA NA
Selectivity yoy_fleet DoubleLogistic slope_desc NA NA NA 10.0000000 constant NA NA NA NA NA
Maturity NA Logistic inflection_point NA NA NA 1.9999914 constant NA NA catch_at_age NA NA
Maturity NA Logistic slope NA NA NA 2.2306407 constant NA NA catch_at_age NA NA

Fit the FIMS Model

After configuring model structure and parameter values, the FIMS estimation model can be initialized and optimized.

The workflow below:

  • Initializes the FIMS model object using the prepared data and parameter values.
  • Runs optimization to estimate model parameters.
  • Extracts estimated quantities for downstream comparison with the OM “truth”.
  • Clears the FIMS interface to reset the modeling environment.
Click to expand/collapse code
fit_fims <- updated_parameters |>
  FIMS::initialize_fims(data = data_fims) |>
  FIMS::fit_fims(
    optimize = TRUE,
    control = list(
      eval.max = 50000,
      iter.max = 30000,
      trace = 0
    )
  )
#> ✔ Starting optimization ...
#> ℹ Restarting optimizer 3 times to improve gradient.
#> ℹ Maximum gradient went from 0.00509 to 0.00084 after 3 steps.
#> ✔ Finished optimization
#> ✔ Finished sdreport
#> ℹ FIMS model version: 0.10.0.9000
#> ℹ Total run time was 4.35337 seconds
#> ℹ Number of parameters: fixed_effects=50, random_effects=32, and total=82
#> ℹ Maximum gradient= 0.00084
#> ℹ Negative log likelihood (NLL):
#> • Marginal NLL= 1785.15404
#> • Total NLL= 1719.13897
#> ℹ Terminal SB= 396690.92108
Click to expand/collapse code
# Extract estimates
year_lookup <- data.frame(
  year_i = 1:(length(model_years) + 1),
  year = c(model_years, get_end_year(data_fims) + 1)
)

estimates_fims <- FIMS::get_estimates(fit_fims) |>
  dplyr::left_join(
    year_lookup,
    by = c("year_i")
  ) |>
  dplyr::mutate(
    uncertainty_label = "se",
    estimate = estimated,
    age = age_i
  )

asc_ip  <- estimates_fims |>
  dplyr::filter(module_id == 1, label == "inflection_point_asc") |>
  dplyr::pull(estimated)
asc_s   <- estimates_fims |>
  dplyr::filter(module_id == 1, label == "slope_asc") |>
  dplyr::pull(estimated)
desc_ip <- estimates_fims |>
  dplyr::filter(module_id == 1, label == "inflection_point_desc") |>
  dplyr::pull(estimated)
desc_s  <- estimates_fims |>
  dplyr::filter(module_id == 1, label == "slope_desc") |>
  dplyr::pull(estimated)

# Compute true peak max across ages
s_asc     <- 1 / (1 + exp(-asc_s * (ages - asc_ip)))
s_desc    <- 1 / (1 + exp(-desc_s * (ages - desc_ip)))
s_max_estimated <- max(s_asc * (1 - s_desc))

estimates_fims <- estimates_fims |>
  # Multiply estimated fishing mortality by max selectivity
  dplyr::mutate(
    estimate = dplyr::if_else(
      label == "log_Fmort" & module_id == 1,
      log(exp(estimate) * s_max_estimated),
      estimate
    )
  )
FIMS::clear()
estimates_fims |>
  dplyr::filter(estimation_type == "fixed_effects" | estimation_type == "random_effects") |>
  dplyr::select(module_name, label, fleet, year_i, age_i, input, estimated, uncertainty) |>
  print(n = Inf)
#> # A tibble: 81 × 8
#>    module_name label            fleet year_i age_i   input estimated uncertainty
#>    <chr>       <chr>            <chr>  <int> <int>   <dbl>     <dbl>       <dbl>
#>  1 Fleet       log_Fmort        NA         1    NA -3.82     -3.45        0.258
#>  2 Fleet       log_Fmort        NA         2    NA -3.86     -3.38        0.260
#>  3 Fleet       log_Fmort        NA         3    NA -3.94     -3.29        0.259
#>  4 Fleet       log_Fmort        NA         4    NA -4.19     -3.69        0.257
#>  5 Fleet       log_Fmort        NA         5    NA -3.45     -2.74        0.260
#>  6 Fleet       log_Fmort        NA         6    NA -0.762    -0.177       0.257
#>  7 Fleet       log_Fmort        NA         7    NA -0.930    -0.320       0.259
#>  8 Fleet       log_Fmort        NA         8    NA -0.515     0.116       0.259
#>  9 Fleet       log_Fmort        NA         9    NA  0.111     0.638       0.256
#> 10 Fleet       log_Fmort        NA        10    NA  0.275     0.758       0.258
#> 11 Fleet       log_Fmort        NA        11    NA  0.197     0.778       0.258
#> 12 Fleet       log_Fmort        NA        12    NA  0.869     1.32        0.255
#> 13 Fleet       log_Fmort        NA        13    NA  0.761     1.30        0.257
#> 14 Fleet       log_Fmort        NA        14    NA  1.06      1.44        0.257
#> 15 Fleet       log_Fmort        NA        15    NA  1.46      1.71        0.257
#> 16 Fleet       log_Fmort        NA        16    NA  1.73      1.82        0.257
#> 17 Fleet       log_Fmort        NA        17    NA  2.12      2.20        0.257
#> 18 Fleet       log_Fmort        NA        18    NA  3.41      2.85        0.258
#> 19 Fleet       log_Fmort        NA        19    NA  2.78      2.54        0.254
#> 20 Fleet       log_Fmort        NA        20    NA  4.07      2.97        0.254
#> 21 Fleet       log_Fmort        NA        21    NA  1.83      1.90        0.249
#> 22 Fleet       log_Fmort        NA        22    NA  1.82      1.81        0.248
#> 23 Fleet       log_Fmort        NA        23    NA  1.32      1.63        0.256
#> 24 Fleet       log_Fmort        NA        24    NA  0.998     1.51        0.252
#> 25 Fleet       log_Fmort        NA        25    NA  0.831     1.25        0.252
#> 26 Fleet       log_Fmort        NA        26    NA  0.489     0.928       0.256
#> 27 Fleet       log_Fmort        NA        27    NA  0.0542    0.724       0.257
#> 28 Fleet       log_Fmort        NA        28    NA  0.492     0.930       0.256
#> 29 Fleet       log_Fmort        NA        29    NA -0.0430    0.475       0.256
#> 30 Fleet       log_Fmort        NA        30    NA -0.123     0.285       0.255
#> 31 Fleet       log_Fmort        NA        31    NA -0.512     0.0334      0.257
#> 32 Fleet       log_Fmort        NA        32    NA -0.989    -0.454       0.259
#> 33 Fleet       log_Fmort        NA        33    NA -0.798    -0.333       0.263
#> 34 Fleet       log_q            NA        NA    NA -3.00     -3.07        0.0243
#> 35 Fleet       log_q            NA        NA    NA -3.00     -2.93        0.0984
#> 36 Recruitment log_rzero        NA        NA    NA 25.0      24.4         0.255
#> 37 Recruitment log_devs         NA         2    NA  0         1.47       NA
#> 38 Recruitment log_devs         NA         3    NA  0         1.25       NA
#> 39 Recruitment log_devs         NA         4    NA  0         1.29       NA
#> 40 Recruitment log_devs         NA         5    NA  0         1.17       NA
#> 41 Recruitment log_devs         NA         6    NA  0         1.02       NA
#> 42 Recruitment log_devs         NA         7    NA  0         1.21       NA
#> 43 Recruitment log_devs         NA         8    NA  0         1.26       NA
#> 44 Recruitment log_devs         NA         9    NA  0         1.28       NA
#> 45 Recruitment log_devs         NA        10    NA  0         1.20       NA
#> 46 Recruitment log_devs         NA        11    NA  0         1.07       NA
#> 47 Recruitment log_devs         NA        12    NA  0         1.11       NA
#> 48 Recruitment log_devs         NA        13    NA  0         1.10       NA
#> 49 Recruitment log_devs         NA        14    NA  0         1.15       NA
#> 50 Recruitment log_devs         NA        15    NA  0         0.864      NA
#> 51 Recruitment log_devs         NA        16    NA  0         0.599      NA
#> 52 Recruitment log_devs         NA        17    NA  0         0.410      NA
#> 53 Recruitment log_devs         NA        18    NA  0        -0.401      NA
#> 54 Recruitment log_devs         NA        19    NA  0        -1.06       NA
#> 55 Recruitment log_devs         NA        20    NA  0        -2.00       NA
#> 56 Recruitment log_devs         NA        21    NA  0        -2.79       NA
#> 57 Recruitment log_devs         NA        22    NA  0        -2.57       NA
#> 58 Recruitment log_devs         NA        23    NA  0        -2.38       NA
#> 59 Recruitment log_devs         NA        24    NA  0        -2.40       NA
#> 60 Recruitment log_devs         NA        25    NA  0        -2.06       NA
#> 61 Recruitment log_devs         NA        26    NA  0        -1.70       NA
#> 62 Recruitment log_devs         NA        27    NA  0        -1.31       NA
#> 63 Recruitment log_devs         NA        28    NA  0        -0.849      NA
#> 64 Recruitment log_devs         NA        29    NA  0        -0.509      NA
#> 65 Recruitment log_devs         NA        30    NA  0        -0.180      NA
#> 66 Recruitment log_devs         NA        31    NA  0         0.287      NA
#> 67 Recruitment log_devs         NA        32    NA  0         0.646      NA
#> 68 Recruitment log_devs         NA        33    NA  0         1.06       NA
#> 69 Selectivity inflection_poin… NA        NA    NA  1.5       1.62        0.0743
#> 70 Selectivity slope_asc        NA        NA    NA  2         2.75        0.0580
#> 71 Selectivity inflection_poin… NA        NA    NA  4         2.64        0.441
#> 72 Selectivity slope_desc       NA        NA    NA  1.5       1.18        0.126
#> 73 Selectivity inflection_point NA        NA    NA  3.03      3.34        0.0621
#> 74 Selectivity slope            NA        NA    NA  2.2       2.00        0.0272
#> 75 Population  log_init_naa     NA        NA     1 25.7      25.8         0.0742
#> 76 Population  log_init_naa     NA        NA     2 24.0      24.2         0.0968
#> 77 Population  log_init_naa     NA        NA     3 22.7      23.0         0.106
#> 78 Population  log_init_naa     NA        NA     4 21.2      21.2         0.152
#> 79 Population  log_init_naa     NA        NA     5 19.7      19.5         0.257
#> 80 Population  log_init_naa     NA        NA     6 18.5      18.8         0.360
#> 81 Population  log_init_naa     NA        NA     7 18.0      17.7         0.656

Compare OM and FIMS

The fitted FIMS model can now be compared against the ecosystem OM “truth” used to generate the simulated observations.

Create DSEM inputs

In addition to supporting fisheries stock assessment workflows, {ecosystemom} can also be used to generate candidate inputs for Dynamic Structural Equation Models (DSEMs). These models provide a flexible framework for evaluating ecosystem linkages, environmental drivers, and trophic interactions through time.

The create_dsem_inputs() function:

  • extracts and reshapes ecosystem time-series data,
  • generates candidate SEM pathways based on trophic interactions, and
  • filters trophic links using a user-defined diet composition threshold.

In this example, trophic links are derived from the static Ecopath diet composition matrix, where diet_composition_threshold controls the minimum diet proportion retained in the candidate SEM structure.

# Load diet composition data
data_diet_composition <- load_diet_composition(
  file.path(ewe_nwatlantic_path, "diet_composition.csv")
)

data <- tibble::tibble(
  data_om = list(data_om),
  data_diet_composition = list(data_diet_composition)
)

sem <- create_dsem_inputs(
  data = data,
  focal_functional_group = c("menhaden 0"),
  diet_composition_threshold = 0.05
)

sem[["sem_tibble"]][[1]] |>
  scroll_table()
driver target lag type param_name
zooplankton menhaden_0 0 bottom_up zooplankton_menhaden_0
phytoplankton menhaden_0 0 bottom_up phytoplankton_menhaden_0
detritus menhaden_0 0 bottom_up detritus_menhaden_0
striped_bass_2_5 menhaden_0 0 top_down striped_bass_2_5_menhaden_0
striped_bass_6_plus menhaden_0 0 top_down striped_bass_6_plus_menhaden_0

sem[["sem_lines"]]
#> [1] "zooplankton -> menhaden_0, 0, zooplankton_menhaden_0\nphytoplankton -> menhaden_0, 0, phytoplankton_menhaden_0\ndetritus -> menhaden_0, 0, detritus_menhaden_0\nstriped_bass_2_5 -> menhaden_0, 0, striped_bass_2_5_menhaden_0\nstriped_bass_6_plus -> menhaden_0, 0, striped_bass_6_plus_menhaden_0"

# Fit Dynamic Structural Equation Model (DSEM)
fit_dsem <- dsem::dsem(
  sem = sem[["sem_lines"]],
  tsdata = sem[["data_time_series_sem"]][[1]],
  control = dsem::dsem_control(quiet = TRUE)
)
#> Warning in dsem::dsem(sem = sem[["sem_lines"]], tsdata =
#> sem[["data_time_series_sem"]][[1]], : The ratio of maximum and minimum Hessian
#> eigenvalues is high. Some parameters might not be identifiable.

# Display model summary
fit_dsem |>
  summary() |>
  dplyr::select(path, Estimate, Std_Error, p_value) |>
  knitr::kable(digits = 3)
path Estimate Std_Error p_value
zooplankton -> menhaden_0 -1.478 0.038 0
phytoplankton -> menhaden_0 -2.993 0.261 0
detritus -> menhaden_0 -5.461 0.201 0
striped_bass_2_5 -> menhaden_0 -1.353 0.080 0
striped_bass_6_plus -> menhaden_0 0.944 0.044 0
year <-> year 9.534 0.339 0
month <-> month 3.456 0.123 0
zooplankton <-> zooplankton -0.173 0.006 0
phytoplankton <-> phytoplankton -0.026 0.001 0
detritus <-> detritus 0.009 0.000 0
striped_bass_2_5 <-> striped_bass_2_5 -0.026 0.001 0
striped_bass_6_plus <-> striped_bass_6_plus 0.035 0.001 0
menhaden_0 <-> menhaden_0 0.006 0.000 0

Next steps

Future development of {ecosystemom} will focus on expanding helper functions for initializing and configuring FIMS models directly from ecosystem operating model outputs, and better diagnosing structural matches and mismatches between modeling frameworks. Additional planned extensions include support for a broader suite of ecosystem operating models beyond Ecosim, such as Ecospace, individual-based implementations of Ecospace, and Atlantis, enabling more flexible and general ecosystem-to-assessment simulation workflows across modeling platforms.
